Forward Syslog Options

Protocol Type

There are various ways to transmit syslog messages. In general,they can be sent via UDP, TCP or RFC 3195 RAW. Typically, syslog messages are received via UDP protocol, which is the default. UDP is understood by almost all servers, but doesn’t guarantee transport. In plain words, this means that syslog messages sent via UDP can get lost if there is a network error, the network is congested or a device (like a router or switch) is out of buffer space. Typically, UDP works quite well. However, it should not be used if the loss of a limited number of messages is not acceptable.

TCP and RFC 3195 based syslog messages offer much greater reliabilty. RFC 3195 is a special standardized transfer mode. However, it has not receive any importance in practice. Servers are hard to find. As one of the very few, Adiscon products support RFC 3195 also in the server implementations. Due to limited deployment, however, RFC 3195 is very little prooven in practice. Thus we advise against using RFC 3195 mode if not strictly necessary (e.g. part of your requirement sheet).

TCP mode comes in three flavours. This stems back to the fact that transmission of syslog messages via plain TCP is not yet officially standardized (and it is doubtful if it ever will be). However, it is the most relevant and most widely implemented reliable transmission mode for syslog. It is a kind of unwritten industry standard. We support three different transmission modes offering the greatest compatibility with all existing implementations. The mode “TCP (one message per connection)” is a compatibility mode for Adiscon servers that are older than roughly June 2006. It may also be required for some other vendors. We recommend not to use this setting, except when needed. “TCP (persistent connection)” sends multiple messages over a single connection, which is held open for an extended period of time. This mode is compatible with almost all implementations and offers good performance. Some issues may occur if control characters are present in the syslog message, which typically should not happen. The mode “TCP (octet-count based framing)” implements algorithms of an upcoming (but not yet finalized) IETF standard. It also uses a persistent connection. This mode is reliable and also deals with embedded control characters very well. However, there is only a limited set of receivers known to support it. As of this writing (January 2007), there were no non-Adiscon receivers supporting that mode. We expect progress once the IETF standard is officially out.

As a rule of thumb, we recommend to use “TCP (octet-count based framing)” if you are dealing only with (newer) Adiscon products. Otherwise, “TCP (persistent connection)” is probably the best choice. If you select one of these options, you can also select a timeout. The connection is torn down if that timeout expires without a message beeing sent. We recommend to use the default of 30 minutes, which should be more than efficient. If an installation only occasionally sends messages, it could be useful to use a lower timeout value. This will free up connection slots on the server machine.

Syslog Target Options

Syslog Send mode

File Configuration field:
nSendMode
Description:

The Sendmode has been added since 2018 into all products supporting the forward syslog action. There are two options are available.

Use single syslog server with optional backup server This is the classic syslog send mode which uses a primary syslog server and a secondary backup syslog server if configured.

Use round robin (multiple syslog servers) This new method allows you to configure multiple targets that will be used one by one after a configured amount of messages has been send to each target.

Syslog Server (Syslog Send mode)

File Configuration field:
szSyslogSendServer
Description:
This is the name or IP address of the system to which Syslog messages should be sent to. You can either use an IPv4, an IPv6 Address or a Hostname that resolves to an IPv4 or IPv6 Address.

Syslog Port (Syslog Send mode)

File Configuration field:
nSyslogSendPort
Description:

The remote port on the Syslog server to report to. If in doubt, please leave it at the default value of 514, which is typically the Syslog port. Different values are only required for special setups, for example in security sensitive areas. Set the port to 0 to use the system-supplied default value (which defaults to 514 on allmost all systems).

Instead of the port number, a service name can be used. If so, that name is looked up via the socket service database functions.

Use this backup syslog server if first one fails

File Configuration field:
nEnableBackupServer
Description:
The backup server is automatically used if the connection to the primary server fails. The primary server is automatically retried when the next Syslog session is opened. This option is only available when using TCP syslog.

Amount of messages send to each syslog server before load balancing

File Configuration field:
nRoundRobinMsgCount
Description:
When using round robin mode, this is the amount of messages to be send to each configured syslog server.

Syslog Servers

Syslog Server (Round robin mode)

File Configuration field:
szSyslogServer_[n]
Description:
This is the name or IP address of the system to which Syslog messages should be sent to. You can either use an IPv4, an IPv6 Address or a Hostname that resolves to an IPv4 or IPv6 Address.

Syslog Port (Round robin mode)

File Configuration field:
nSyslogPort_[n]
Description:

The remote port on the Syslog server to report to. If in doubt, please leave it at the default value of 514, which is typically the Syslog port. Different values are only required for special setups, for example in security sensitive areas. Set the port to 0 to use the system-supplied default value (which defaults to 514 on allmost all systems).

Instead of the port number, a service name can be used. If so, that name is looked up via the socket service database functions.

Syslog Message Options

Syslog processing

File Configuration field:

bProcessDuringRelay

  • 0 = Disable processing
  • 1 = RFC3164 Header
  • 2 = RFC5424 Header
  • 3 = Custom Syslog Header
Description:

With this settings you can assign how your syslog messages will be processed.

For processing syslog you can choose out of four different options. You can use RFC3164 or RFC5424 (recommended) which is the current syslog standard, you are able to customize the syslog header or you do not process your syslog and forwards it as it is.

Custom Header Format

File Configuration field:
szCustomSyslogHeader
Description:

In this field you can specify the contents of your syslog header. This option is only available when you choose “Use Custom Syslog Header” in the Syslog Processing menu. The contents can be either a fixed message part which you can write into the field yourself or you use properties as dynamic content. By default the Header field is filled with the content of the RFC 5424 header.

Please note that the header content of the Header field can be configured. Event properties are described in the property replacer section.

Output Encoding

File Configuration field:
nOutputEncoding
Description:
This setting is most important for Asian languages. A good rule is to leave it at “System Default” unless you definitely know you need a separate encoding. “System Default” works perfect in the far majority of cases, even on Asian (e.g. Japanese) Windows versions.

Include UTF8 BOM in message

File Configuration field:
nProtocolType
Description:
If enabled (default), the UTF8 BOM code will be prepended to the output message if you are using UTF8 Output encoding. If the syslog receiver cannot handle and remove the UTF8 BOM you can disabled this option.

Use XML to Report

File Configuration field:
bReportInXML
Description:

If this option is checked, the forwarded Syslog message is a complete XML-formatted information record. It includes additional information like timestamps or originating system in an easy to parse format.

The XML formatted message is especially useful if the receiving system is capable of parsing XML data. However, it might also be useful to a human reader as it includes additional information that cannot be transferred otherwise.

Forward as MW Agent XML Representation Code

File Configuration field:
nForwardIUT
Description:

MonitorWare supports a specific XML-Representation of the event. If it is checked, that XML representation is used. It provides additional information (like informationunit type, original source system, reception time & many more) but is harder to read by a human. At the same time, it is obviously easier to parse. Please note that this option is only “experimental” and is not an official standard.

Use CEE enhanced Syslog Format

If enabled, the new CEE enhanced Syslog format will be used (work in progress). All useful properties will be included in a JSON Stream. The message itself can be included as well, see the “Include message property in CEE Format” option. Here is a sample how the format looks like for a security Eventlog message:

@cee: {“source”: “machine.local”, “nteventlogtype”: “Security”, “sourceproc”: “Microsoft-Windows-Security-Auditing”, “id”: “4648”, “categoryid”: “12544”, “category”: “12544”, “keywordid”: “0x8020000000000000”, “user”: “N\A”, “SubjectUserSid”: “S-1-5-11-222222222-333333333-4444444444-5555”, “SubjectUserName”: “User”, “SubjectDomainName”: “DOMAIN”, “SubjectLogonId”: “0x5efdd”, “LogonGuid”: “{00000000-0000-0000-0000-000000000000}”, “TargetUserName”: “Administrator”, “TargetDomainName”: ” DOMAIN “, “TargetLogonGuid”: “{00000000-0000-0000-0000-000000000000}”, “TargetServerName”: “servername”, “TargetInfo”: ” servername “, “ProcessId”: “0x76c”, “ProcessName”: “C:\Windows\System32\spoolsv.exe”, “IpAddress”: “-“, “IpPort”: “-“, “catname”: “Logon”, “keyword”: “Audit Success”, “level”: “Information”, }

Additionaly to this format you can set Include message property in CEE Format

If enabled, the message itself will be included in the JSON Stream as property. Disable this option if you do not want the message itself in the CEE Format.

Please note you can also make Event ID part of the actual Syslog message while forwarding to a Syslog Server then you have to make some changes in the Forward Syslog Action. Click here to know the settings.

Clear logfile instead of deleting (File will be reused)

File Configuration field:
szSMTPSubject
Description:

Subject line to be used for outgoing emails and it is used for each message sent. It can contain replacement characters or “Event Properties” to customize it with event details. This is especially useful when sending email to cellular phones or pagers, which often display only the subject line and not the actual message body. The subject line – after expansion of the any replacement sequences – can hold a maximum of 255 characters. Characters beyond this will be truncated. Please note that many email systems impose a more strict limit and truncation may occur before the 255-character limit. It is advisable to limit the subject line length to 80 characters or less.

The mail body will also include full event information, including the source system, facility, priority and actual message text as well as any other information that came with this event. As there is no size limitation for message bodies, the body always contains the full message received (except otherwise configured – see below).

Please note that Insert Menu entry allows you to add replacement characters e.g. %msg% - you can send out the actual message of an event in the subject line.

There will be one email for each received message. Email delivery is meant for urgent notifications and actions (e. g. calling pagers and such). It is not meant to provide an email report.

Please note that The message content of the Message field can be configured. Event properties are described in the property replacer section.

Mail Priority

File Configuration field:

nMailPriority

  • 0 = low
  • 1 = Default
  • 2 = High
Description:
Here you can adjust the priority with which the mail will be sent. You can choose between “low”, “normal” and “high” priority. With this you can give your setup some complexity, being able to send some events as “important” and others with less importance.

Mail Message Format

File Configuration field:
szSMTPBody
Description:
This is the format of the message body. Properties from the event can be included by using the Property Replacer. Please note that the message body is only sent if “Include Message/Event in Email Body” is checked.

Output Encoding

File Configuration field:
nOutputEncoding
Description:
Determines the character encoding mode.

Include message / event in email body

File Configuration field:
nIncludeMessage
Description:

This checkbox controls whether the Syslog message will be included in the message body or not. If left unchecked, it will not be included in the body. If checked, it will be sent.

This option is useful for pagers and mobile phones, especially those with WML support. These devices are often capable of displaying only limited amounts of data. Some do not display the message body at all. As such, it makes limited sense to send a message body. As such, it can be turned off with this option. With these devices, use a subject line with the proper replacement characters.

Even if your WML enabled phone supports receiving message bodies, it might be a good idea to turn them off. WML and WAP are relatively expensive. Generated messages can become lengthy (depending on the message source). As such, it might be appropriate to disable the message body in such a scenario.

This option is must useful together with a well-formatted subject line in non-legacy mode.

Use XML to Report

File Configuration field:
nUseXMLtoReport
Description:

If checked, the received event will be included in XML format in the mail. If so, the event will include all information, like the original timestamp, the facility, priority etc. XML format is especially useful if the mail is sent to an automated system, which will then parse the message.

If unchecked, just the plain text message will be included in the mail. This format is more readable for a human reader.
